SM31P11-32/SM31S11-32 Safety Limit Switches

|
Features：
· Sub-body style
· Modular
· IP67 Waterproof model
Model:
SM31P11-32 : Snap Action
SM31S11-32 : Slow Action
|
Specifications:
Operating Speed: 0.05mm-2m/sec
Operating Frequency:Mechanical:120ops/min
Electrical: 30ops/min
Insulation Resistance: >100MΩ @ 500V DC
Contact Resistance: <25mΩ
Rated Current/Voltage: 5A/300V AC (EN60947-5-1)
Electrical Rating: AC15 A600/ DC13 Q300
Dielectric Strength: 1000VAC for 1 min
between non-continuous terminals
2500VAC for 1 min
between each terminal and ground
Service Life:Mechanically 10,000,000, Electrically 500,000
Operating Temperature:
-25~80℃(-13~176°F) without formation of ice
Humidity: <95%RH
Cable： 5 core:0.75mm²
7 core: 0.5mm²
9 core: 0.34mm²
Degree of protection: IP67
|
