Compact Limit Switches SN3221(25mm)4-CORE

|
Features：
*Easy to install
*Golbal general standard
*M12 aviation connector available
|
Specifications:
Operating Speed: 0.05mm-2m/sec
Operating Frequency: Mechanical:120ops/min Electrical: 30ops/min
Insulation Resistance: >100MΩ @ 500V DC
Rated Current/Voltage: 10A/300V AC (EN60947-5-1)
Electrical Rating: UL/cUL Listed(E216958) for AC15 A300/ DC13 Q300
Service Life: Mechanically 10,000,000, Electrically 500,000
Operating Temperature: -25~85℃ without formation of ice
Degree of protection: IP67
|
