MINI ENCLOSED LIMIT SWITCHES SN7312-W

|
|
Specifications:
Operating Speed: 0.05mm-0.5m/sec(panel mount plunger)
Operating Frequency: Mechanical: 120ops/min Electrical: 30ops/min
Contact Resistance: <15mΩ(initial value)
Insulation Resistance: >100mΩ@500V DC
Rated Voltage: 250VAC
Rated Current: 10A
Operating Temperature: -20 ~ +60°(-4~+140°F)
Dielectric Strength: 1000VAC for 1 min between non-continuous terminals
2500VAC for 1 min between each terminal and ground
Service Life: Mechanically 10,000,000, Electrically 500,000
Humidity: <95%RH
Weight: ~60g
Degree of Protection: IP64 (IP67 for model with -w suffix)
|
