Features: *NC & NO available
* Unshielded &shielded available
*Meet GB14048.10
*protection with short circuit
*protection with polar
*degree of protection:IP67
Installation dimensions:
Specifications: Rated voltage 10 ～ 36VDC
Rated current <10mA( 24 v )
Load current 200mA
Repeatability < 5%
Hysteresis 10%
Leakage current (max) < 10uA
voltage drop < 2VDC
operature temperature -25～70℃
EMC GB14048.10
degree of protection IP67
