SUNS-CPB30-P Series Capacitive Pushbutton (IP69K)

CPB30-P Series Capacitive Pushbutton (IP69K)

　Features：
　*Robustic stainless steel housing design
*Touch control, no mechanical force required
*Ideal for pharmaceutical, medical and food industries
*Housing design conform to DIN EN1672-1/2 (Hygiene)
*IP69K rated. Easy to clean.

Specifications:
Supply Voltage: 10-30VDC
Switching Current: 200mA
Output Type: PNP-NO (or NPN)
Reverse Polarity Protection: Yes
Short Circuit Protection: Yes
Voltage Drop: Max. 2V @200mA
Current Consumption: Max. 20mA @24V
OperatingTemperature: -30~+70oC (-22 ~158oF)
Service Life: 100 million (operatings)
Degree of Protection: IP69K (Front), IP67 (Back)

SUNS Address:127 Rivemeck Road, Chelmsford, MA01824
Phone:+1-978-349-2329 Fax:+1-978-349-2330　E-mail:info@suns-usa.com
