HCX_3N/4N Explosion Proof Limit Switches
Features: |
Specifications: Operating speed: 0.05mm-0.2m/sec Service life:10 million (minimum)                 Electrical 1 million (minimum) Operating temperature: -28.9 ~ +85 ℃ (-20 ~ 185 ° F) Vibration: 25gn (10 .. 150Hz, 11ms) per IEC60068-2-6 Impact: 60gn (9ms) per IEC60068-2-27 Dielectric strength: 2200VAC for 1 minute Terminal line: 12-22AWG (2.05-0.644 square mm) Degree of protection: IP67                                NEMA Types 2,4,6,6 P,13 HCX Hazardous Location Ratings: CLASS I DIV1&DIV2 GROUPS B,C,D CLASS II DIV1&DIV2 GROUPS E,F,G ATEX/IEC Ex, INMETRO (Gas) II 2 G;Exd IIC T6 ATEX/IEC Ex, INMETRO (Dust) II 2 D; Exd tD A21 T85oC |
