Compact Precision Limit Switches SN1121

　Features：
　* Robust metal enclosure design
* Compact space-saving and tightly gang mounting possible
* High sealability oil-resistant/Immersion-proof type
* Long mechanical life of 10 million operations
* High sensitivity (M.D. =0.1mm)
* Gold plated contact available for low current applications
* M12 connector type available

Specifications:
Operating Speed: 0.02mm-0.5m/sec
Operating Frequency: 120ops/min
Insulation Resistance: >100mΩ@500VDC
Contact Resistance: <25mΩ
Electrical Rating： Standard Load Type (Silver contacts)5A/250VAC or 5A/30VDC
Low Current type (Gold Plated Contacts) 0.1A/250VAC or 0.1A/30VDC
Dielectric Strength: 1000VAC for 1 min between current carrying parts
2500VAC for 1 min between non-current carrying parts
Service Life: Mechanically 10000000 (operations)
Electrically 500000 (operations)
Operating Temperature: -30~+80°C (-22~+176°F)
Humidity: <98%RH
Degree of Protection: IP67
