FS-81-CS Series Medical Foot Switches

Features: •Maximum protection provided for accidental activation, minimum dimension •High mechanical stability •Push to open/push to close •Foot pedal material: glass fiber reinforced plastic or zinc die cast •Zinc die cast base with fiber reinforced plastic protective cover

Installation dimensions:

Specifications: Operating Frequency 60 ops/min Insulation Resistance >100mΩ@500V DC Contact Resistance <25mΩ(initial) Rated Current/Voltage Ith: 10A Ui: 300V AC UL Rating: A300/AC15 CCC Rating: 10A/250V IEC60601 (TUV): 5A/25VAC Dielectric Strength 1000VAC for 1 min between current carrying parts 2500VAC for 1 min between non-current carrying parts Service Life 1 x106 (operations) Operating Temperature --30~+80oC (-22~176oF) Degree of Protection IPX8 (NEMA 4, 4x, 6, 6P)

TRADEMARK INFORMATION:
All trademarks, trade names, or logos mentioned or used are the property of their respective owners.



TRADEMARK INFORMATION:
All trademarks, trade names, or logos mentioned or used are the property of their respective owners.

TYPE:FS-81-CS View Details
